| Features |
|
Running cost can be reduced by using the thinnest film of 40u OPP !
● Environmental friendly paper tapes are used so that problems of damaging the corner or edge of product can be prevented.
● Very easy operations requiring no experienced operators.
● Many different models for different applications using the most suitable tapes in a range of 30mm up to 150mm.
● Printed mark positioning system can be included in the machine ( optional system ).
● We can offer customized machine.
ex. special Arch size - 600mm(W) x 700mm(H), 1100mm(W) x 1000mm(H) ......
|
| Suitable |
|
A unique model ideal for banding medicines, cosmetics, foods, and various printed products. Special sizes according to the user's requirements can be designed and produced.
|
| Specification |
● Sealing method：Welding by hot plate.
● Tape：Up to 75g Craft paper tape、Up to 80g White paper tape、40u or Up to 40u OPP film -30mm, 50mm, 75mm, 100mm and 150mm(W). Please use the designated TAPE.
● Power ：110/220V 60/50Hz.
● Banding speed ：22 times/minute.
● Power supply ：110/220V 60/50Hz.
● Machine model ：
WAS-250 – According to Arch size：250mm(W) x 270mm(H).
WAS-400 – According to Arch size：400mm(W) x 270mm(H).
|
● Machine Specification：Follow above.
Please choose Arch size in advance, then choose the TAPE width.
|
TAPE width 30/50mm
|
WAS-250-30/50
|
WAS-400-30/50
|
|
Machine size- width
|
614mm
|
681mm
|
|
- High
|
1292mm
|
|
- Depth
|
412mm
|
|
Table height
|
926mm
|
|
Printed mark positioning
|
Option ( preliminary arrangement )
|
|
TAPE width 75/100mm
|
WAS-250-75/100
|
WAS-400-75/100
|
|
Machine size- width
|
614mm
|
681mm
|
|
- High
|
1292mm
|
|
- Depth
|
465mm
|
|
Table height
|
926mm
|
|
Printed mark positioning
|
Option ( preliminary arrangement )
|
|
TAPE width 150mm
|
WAS-250-150
|
WAS-400-150
|
|
Machine size- width
|
614mm
|
681mm
|
|
- High
|
1292mm
|
|
- Depth
|
565mm
|
|
Table height
|
926mm
|
|
Printed mark positioning
|
Option ( preliminary arrangement )
|
※ Use of 150mm printed tape will look like wrapped product after banding in this machine.
